EL-RL200 Electric Rim lock

The EL-RL200 electric rim lock system is meant for both electrical and hand (physical) control.
Suitable to be equipped with intercom system or access control system.

Specification:

Operating Voltage: 9 ~ 12VDC
Operating Current: 800mA

Technical Specification

~ Voltage : DC12V ±10%

~ Unlocking Current : 1.5A~3A

~ Min Unlocking Power : 10W

~ Coil Ground Insulation : DC 500V

~ Energizing : Discontinuous, Energized <7S

~ Unlocking Time : 0.5S

~ Temperature : −40⁰C ~ 50⁰C

~ Static Pressure : 6000N

~ Service Life : 300,000 times

~ IP Rating : IP40
