Description
⭐️FEATURES⭐️
- The torque generated by engine or electric motor is transferred to reciprocating motion by crank gear, which will pass it on vibrating foot (shoe) through spring cylinder
- Wear-resistant compaction steel base provides long lasting durability and better compaction finish.
- Durable rotor assembly and clutch pulley assembly saves maintenance cost.
- Heavy duty rubber mountings and rubber absorbes made from natural rubber limits vibration towards handle to better protect engine and operator.
- Strong steel belt cover to prevent dirt out of the belt and higher safety
- Equipped with heavy duty clutch and strong exciter.
⭐️SPECIFICATIONS⭐️
▪️ Vibration Plate Compactor
- Model : YP-80
- Base Plate Dimension : L530mm x W425mm
- Vibrating Frequency (vpm) : 6100
- Travel Speed (m/min) : Up to 20
- Grade Ability (deg) : Up to 15
- Centrifugal Force (kN/kgf) : 15/1550
- Min compaction depth (cm) : 20
▪️ Engine
→ HISAKI LP220Q
- Engine Type : Single cylinder , 4 stroke (OHV)
- Bore*Stroke : 70*55(mm)
- Displacement : 212CC
- Compression ratio : 9.0:1
- Net Power : 4.1kW / 3600RPM
- Net Torque : 12NM / 2500RPM
- PTO Shaft rotation : Counter clockwise (horizontal shaft output)
- Ignition System : Electromagnetic ignition
- Starting system : Recoil
- Carburetor : Float carburetor
- Oil capacity : 0.6L
